MOSKYAUDIO Audio Bright Flame Multi Guitar Amp Simulator Pedal Stereo Cabinet Sim Box Preamp DI Box Effect Pedal

The amplifier that will fit in your pedalboard, thanks to its stereo mic’d cabinet simulation, stereo FX loop, tube-like power amp stage, and a full featured clean preamp based on 3 classic amps.

Current consumption: 50mA to 100mA (if Headphone out is used) ;Supply voltage: 9V – 12V

Polarity: Center negative

Input impedance: 1 Meg Ohm ;TRS output impedance: 100 Ohm ;DI Output impedance: 120 Ohm;

Send output impedance 100 Ohm; Return Input Impedance: 1 Meg ohm; Headphone Power : 120mW @ 32 Ohm

FX Send:

PLEASE NOTE THAT WHEN USING FX LOOPS SOME EFFECTS ALLOWS YOU TO CHOOSE BETWEEN LINE/MIC LEVEL.

ON UNDESIRED CLIPPING RETURNING FROM THE FX LOOP. IF YOUR DEVICE,DOESN’T HAVE A SELECTABLE GAIN ADJUSTMENT, PLEASE TAKE CARE ON

SETTING UP FIRST YOUR DESIRED AMOUNT OF GAIN IN THE PREAMP SECTION,THEN ADJUST THE VOLUME.

FX return Right (mono): Connect the right (mono) output from your stereo effects here.

FX return Left: Connect the left side of your effects here. If this input is unconnected,

the left side will take the signal from the FX Return Right (mono) side.

TRS Right (mono) Out: Carries the right side output or the input signal (bypass), if selected.

TRS Left : Carries the left side output or the input signal (bypass), if selected. If the left side is disconnected and not in bypass mode, the Right side will sum both outputs.

DI Right: Carries the Right side output in a balanced signal.

DI Left: Carries the Left ide output in a balanced signal.

Aux In: The auxiliary input receives a signal from an mp3 player, phone, or any audio device, and sends the signal in stereo to the headphone out. Perfect for monitoring or late night practice.

Technical Specs

Colour:Dark Blue

Material:Metal

Package Contents:

1 * Guitar Pedal

Only the above package content, other products are not included.

Note: Light reflection and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
